HP Clear Film - 610 mm x 22.9 m

Give your ideas a photo-realistic finish
Keep your projects on track and demonstrate the quality and professionalism of your work with this optically clear, recyclable film. Produce multiple overlays and transparent images with excellent line quality and consistent, vivid color.

Accomplish more with consistent results every time
Look to this professional-quality film to present your professional best. Produce sharp line quality and consistent, vivid color with a film designed to provide excellent bleed control and strong ink adhesion to prevent ink transfer between overlays.

Keep a brisk pace from one project to the next
Meet your project deadlines. Compatible with a wide range of HP DesignJet printers using both Original HP dye- and pigment-based inks, this optically clear film provides high-quality, consistent image quality print to print and roll to roll.

Print with the environment in mind
Help meet the environmental objectives of your company—and your clients. HP Clear Film is included in the HP Large Format Media take-back program1, a free and convenient return and recycling program.

Target customers Applications Benefits
Architects

Trade show and event displays

Sharp line quality; consistent, vivid color

Engineers

POP and retail displays

Excellent bleed control for sharp images

Geographic Information Systems
(GIS) professionals

Geographic Information Systems (GIS)

Strong ink adhesion prevents ink transfer between layers

Architecture (AEC) and engineering (MCAD)

Compatible with both Original HP dye- and pigment-based inks

Recyclable through the HP Large Format Media take-back program

Technical Specifications
Weight

156 g/m² per ISO 536 Test Method

Thickness

119 microns/4.7 mil per ISO 534 Test Method

Opacity

8% per TAPPI T-425 Test Method

Brightness

Greater than 95% per TAPPI T-452 Test Method

Whiteness

130 per CIE Ganz 82 Test Method

Finish

Matte

Operating temperature

15 to 35° C / 59 to 95° F

Operating humidity

20 to 70% RH

Dry time

Less than 9 minutes (at 23° C, 50% RH)

Lamination

Yes, compatible with thermal, heat assist, and pressure-sensitive film laminates

Shelf life

2 years, unopened in original packaging

Storage temperature

5 to 40° C / 41 to 104° F

Storage humidity

10 to 80% RH

Environmental

Recyclable through commonly available recycling programs

Country of origin

Product of Germany

Imperial Metric
Width 24 in 610 mm
Length 75 ft 22.9 m
Config 1 Roll 1 Roll
Printer DesignJet 500
Printer DesignJet T1120
Printer DesignJet T2300
Printer DesignJet T2500/T2530
Printer DesignJet T7100
Printer DesignJet T520
Printer DesignJet T790
Printer DesignJet T610
Printer DesignJet T620
Printer DesignJet T1100
Printer DesignJet T1300
Printer DesignJet T1500/T1530
Printer DesignJet T120
Printer DesignJet T770
Printer DesignJet T795
Printer DesignJet T1200
Printer DesignJet T920
Printer DesignJet T3500
Printer DesignJet T7200
Printer DesignJet 510
Product Group HP Clear Flim
Printer DesignJet T730
Printer DesignJet T830
Printer DesignJet T930
Printer DesignJet Z2100
Printer DesignJet Z3200
Printer DesignJet Z3100
Printer DesignJet Z5400
Printer DesignJet Z6100
Printer DesignJet Z6200
Printer DesignJet Z6800
Printer DesignJet Z5200
Printer DesignJet Z6600
Printer DesignJet 5000 Dye
Printer DesignJet 5500 Dye
Printer DesignJet D5800
Printer DesignJet Z5600
Weight (gsm) 174
Thickness (micron) 132
Thickness (mil) 5.2
Printer DesignJet Z3200PS
Printer DesignJet Z3100PS
Printer DesignJet Z6810
Printer DesignJet Z6610
Printer DesignJet 111
Printer DesignJet T1700
Printer DesignJet 110
Printer DesignJet 110Plus
Printer DesignJet 110Plus NR
Printer DesignJet T7100 Monochrome
Printer DesignJet 4500
Printer DesignJet 4520
Printer DesignJet 4000
Printer DesignJet 4020
Printer DesignJet 1050C
Printer DesignJet 1055CM
Printer DesignJet 1050C Plus
Printer DesignJet 1055CM Plus
Printer DesignJet 500 Plus
Printer DesignJet 500PS
Printer DesignJet 510PS
Printer DesignJet Z6
Printer DesignJet Z9
Printer DesignJet Z2600
Printer DesignJet XL 3600
Printer DesignJet T100
Printer DesignJet T125
Printer DesignJet T130
Printer DesignJet T525
Printer DesignJet T530
Printer DesignJet T1600
Printer DesignJet T2600
Ink Compatibility Aqueous
